DMX Decoder adopted the advanced micro-electronic control technology to convert universal DMX512/1990 digital signal to CC/CV PWM signal to drive LED, which controlled by DMX512 console, realize 0-100% brightness or various changing effect. And can control single color, dupi-color, RGB, RGBW, RGBWY, RGBWW LED lights.
| Input signal | DMX512, RDM |
| Input Voltage | 12-48V |
| Output Current | 8A×3CH 6A×4CH Max.24A |
| Output Voltage | 4×(12-48V) |
| Output Power | 288W@12V 576W@24V 864W@36V 1152W@48V |
| Dimming Range | 0-100% |
| Working Temp. | -25°C-55°C |
| Dimensions(L×W×H) | L175×W46×H30(mm) |
| Package Size(L×W×H) | L187×W52×H36(mm) |
| Weight (G.W) | 325g±5g |
| Protection | Short circuit, over temperature, over current protection, auto recovery. |
| Input signal | DMX512, RDM |
| Input Voltage | 5-24V |
| Output Current | 2A×5CH Max. 10A |
| Output Voltage | 5×(5-24V) |
| Output Power | 50W@5V 120W@12V 240W@24V |
| Dimming Range | 0-100% |
| Working Temp. | -25°C-50°C |
| Dimensions(L×W×H) | L76×W25.5×H11mm |
| Weight (G.W) | 11g±3g |
| Protection | Short circuit, over-temperature, anti-reverse protection and self recovery. |
| Input signal | DMX512, RDM |
| Input Voltage | 12-48V |
| Output Current | 8A×3CH 6A×4CH Max.24A |
| Output Voltage | 4×(12-48V) |
| Output Power | 288W@12V 576W@24V 864W@36V 1152W@48V |
| Dimming Range | 0-100% |
| Working Temp. | -25°C-55°C |
| Dimensions(L×W×H) | L175×W46×H30(mm) |
| Package Size(L×W×H) | L187×W52×H36(mm) |
| Weight (G.W) | 325g±5g |
| Protection | Short circuit, over temperature, over current protection, auto recovery. |
| Input signal | DMX512, RDM |
| Input Voltage | 5~24Vdc |
| Current Load | 6A×3CH Max. 18A |
| Output Power | 90W@5V 216W@12V 432W@24V |
| DMX512 Socket | Green Teminal |
| Protection | Short circuit / Over current protection |
| Working Temp. | -25℃~55℃ |
| Dimensions | L175×W42×H33mm |
| Package Size | L183×W48×H41mm |
| Weight (G.W) | 310g |
| Input signal | DMX512, RDM |
| Input Voltage | 12~24Vdc |
| Current Load | 5A×4CH Max. 20A |
| Output Power | (0~60W...120W)×4CH Max.480W |
| DMX512 Socket | Green Teminal |
| Protection | Short circuit / Over load recover automatically |
| Working Temp. | -25℃～65℃ |
| Dimensions | L175×W42×H33mm |
| Package Size | L183×W48×H41mm |
| Weight (G.W) | 310g |
| Input signal | DMX512, RDM |
| Input Voltage | 5~24Vdc |
| Current Load | 6A × 4CH 8A × 3CH |
| Output Power | 120W@5V 288W@12V 576W@24V |
| DMX512 Socket | 3-pin XLR, RJ45, Green Terminal |
| Dimming Range | 0-100% |
| Protection | Short circuit / Over current |
| Working Temp. | -25℃~55℃ |
| Dimensions(L×W×H) | L156 × W78 × H40(mm) |
| Package Size(L×W×H) | L180 × W82 × H48(mm) |
| Weight (G.W) | 445g |
| Input signal | DMX512/RDM |
| Input Voltage | 12-24V |
| Output Current | Max. 5A/CH Max. 20A(4CH) |
| Output Power | (0-60...120)W/CH Max. 480W(4CH) |
| Dimming Range | 0-100% |
| Working Temp. | -20°C~50°C |
| Dimensions(L×W×H) | L164×W70×H36mm |
| Package Size(L×W×H) | L193×W127×H41mm |
| Weight (G.W) | 690g |
| Protection | Short circuit, over temperature, over current protection, auto recovery. |
| Input signal | DMX512/RDM |
| Input Voltage | 100-240V~ |
| Output Current | Max. 1.2A/CH Max. 3.6A(3CH) |
| Output Power | (83-288)W/CH Max. 864W(3CH) |
| Dimming Range | 0-100% |
| Working Temp. | -20°C~50°C |
| Dimensions(L×W×H) | L164×W70×H36mm |
| Package Size(L×W×H) | L193×W127×H41mm |
| Weight (G.W) | 670g |
| Protection | Short circuit, over temperature, over current protection, auto recovery. |
| Input signal | DMX512/RDM |
| Input voltage | DC12V～DC24V |
| Max load current | 3A × 16CH Max 48A |
| Max output power | (0~36W...72W) × 16CH Max. 1152W |
| DMX512 socket | 5-pin XLR, RJ45, Green terminal |
| Control mode | Dimming/CT/RGB/RGBW |
| DIM Curve | 0.1～9.9 |
| Gray scale level | 8bit(256 levels)/16bit(65536 levels) |
| Photoelectric Isolation | Yes |
| Working temperature | -30℃～65℃ |
| Dimension | L180×W122×H39mm |
| Package Size | L193×W127×H41mm |
| Weight (G.W) | 730g |
| Input signal | DMX512/RDM |
| Input voltage | DC12V～DC24V |
| Max load current | 3A × 16CH Max 48A |
| Max output power | (0~36W...72W) × 16CH Max. 1152W |
| DMX512 socket | 3-pin XLR, RJ45, Green terminal |
| Gray scale level | 8bit (256 levels) / 16bit (65536 levels) |
| Working temperature | -30℃～65℃ |
| Dimension | L180×W122×H39mm |
| Package Size | L193×W127×H41mm |
| Weight (G.W) | 730g |
| Input signal | DMX512/RDM |
| Input voltage | DC12V～DC24V |
| Max load current | 6A x 5CH Max. 30A |
| Max output power | (0~72W...144W) x5CH Max. 720W |
| DMX512 socket | 3-pin XLR, RJ45, green terminal |
| Gray scale level | 8bit (256 levels) / 16bit (65536 levels) |
| Working temperature | -30℃～65℃ |
| Dimension | L169×W80×H39mm |
| Package Size | L182×W91×H41mm |
| Weight (G.W) | 550g |
| Input signal | DMX512/RDM |
| Input voltage | DC12V～DC24V |
| Max load current | 3A × 32CH Max 96A |
| Max output power | (0~36W...72W) × 32CH Max. 2304W |
| DMX512 socket | 3-pin XLR, 5-pin XLR, RJ45, Green terminal |
| Gray scale level | 8bit (256 levels) / 16bit (65536 levels) |
| Working temperature | -30℃～65℃ |
| Dimension | L300×W122×H39mm |
| Package Size | L313×W127×H41mm |
| Weight (G.W) | 1180g |
| Input signal | DMX512/RDM |
| Input voltage | DC12V～DC24V |
| Max load current | 3A × 24CH Max 72A |
| Max output power | (0~36W...72W) × 24CH Max. 1728W |
| DMX512 socket | 3-pin XLR, 5-pin XLR, RJ45, Green terminal |
| Gray scale level | 8bit (256 levels) / 16bit (65536 levels) |
| Working temperature | -30℃～65℃ |
| Dimension | L300×W122×H39mm |
| Package Size | L313×W127×H41mm |
| Weight (G.W) | 1180g |
| Input signal | DMX512/RDM |
| Input voltage | DC12V～DC24V |
| Max load current | 4A × 12CH Max 48A |
| Max output power | (0~48W...96W) × 12CH Max. 1152W |
| DMX512 socket | 3-pin XLR, RJ45, Green terminal |
| Gray scale level | 8bit (256 levels) / 16bit (65536 levels) |
| Working temperature | -30℃～65℃ |
| Dimension | L180×W122×H39mm |
| Package Size | L193×W127×H41mm |
| Weight (G.W) | 730g |
| Input signal | DMX512/RDM |
| Input voltage | DC12V～DC24V |
| Max load current | 5A x 5CH Max. 25A |
| Max output power | (0~60W...120W) x5CH Max. 600W |
| DMX512 socket | 3-pin XLR, RJ45 |
| Gray scale level | 8bit (256 levels) / 16bit (65536 levels) |
| Working temperature | -30℃～65℃ |
| Dimension | L122×W110×H37(mm) |
| Package Size | L127×W123×H41mm |
| Weight (G.W) | 550g |
| Input signal | DMX512/RDM |
| Input voltage | DC12V～DC24V |
| Max load current | 6A x 4CH Max. 24A |
| Max output power | (0~72W...144W) x4CH Max. 576W |
| DMX512 socket | 3-pin XLR, RJ45 |
| Working temperature | -30℃～65℃ |
| Dimension | L122×W110×H37(mm) |
| Package Size | L127×W123×H41mm |
| Weight (G.W) | 550g |
| Input signal | DMX512/RDM |
| Input voltage | DC12V～DC24V |
| Max load current | 6A x 4CH Max. 24A |
| Max output power | (0~72W...144W) x4CH Max. 576W |
| DMX512 socket | 3-pin XLR, RJ45 |
| Gray scale level | 8bit (256 levels) / 16bit (65536 levels) |
| Working temperature | -30℃～65℃ |
| Dimension | L122×W110×H37(mm) |
| Package Size | L127×W123×H41mm |
| Weight (G.W) | 550g |
| Input signal | DMX512/RDM |
| Input voltage | DC12V～DC24V |
| Max load current | 8A x 3CH Max. 24A |
| Max output power | (0~96W...192W) x3CH Max. 576W |
| DMX512 socket | 3-pin XLR, RJ45 |
| Working temperature | -30℃～65℃ |
| Dimension | L122×W110×H37(mm) |
| Package Size | L127×W123×H41mm |
| Weight (G.W) | 550g |
| Input signal | DMX512/RDM |
| Input voltage | DC12V～DC24V |
| Max load current | 8A x 3CH Max. 24A |
| Max output power | (0~96W...192W) x3CH Max. 576W |
| DMX512 socket | 3-pin XLR, RJ45 |
| Gray scale level | 8bit (256 levels) / 16bit (65536 levels) |
| Working temperature | -30℃～65℃ |
| Dimension | L122×W110×H37(mm) |
| Package Size | L127×W123×H41mm |
| Weight (G.W) | 550g |
| Input signal | RDM DMX512 |
| Input voltage | 5~24Vdc |
| Output | 6A×3CH Max. 18A |
| Max output power | (0~30W...144W)×3CH Max. 432W |
| DMX512 socket | RJ45 |
| Dimming range | 0~100% |
| Working temperature | -30℃～65℃ |
| Dimension | L175×W42×H33mm |
| Package Size | L183×W48×H41mm |
| Weight (G.W) | 310g |
| Input signal | DMX512/RDM |
| Input voltage | DC12V～DC24V |
| Max load current | 5A ×5CH Max. 25A |
| Max output power | (0~60W...120W) x5CH Max.600W |
| DMX512 socket | XLR-5, RJ45 |
| Control mode | DIM/CT/RGB/RGBW/RGBWY |
| DIM Curve | 0.1～9.9 |
| Gray scale level | 8bit(256 levels)/16bit(65536 levels) |
| Photoelectric Isolation | Yes |
| Working temperature | -30℃～65℃ |
| Dimension | L122×W110×H37(mm) |
| Package Size | L125×W115×H39(mm) |
| Weight (G.W) | 450g |
| Input signal | DMX512/RDM |
| Input voltage | DC12V～DC24V |
| Max load current | 6A ×5CH Max. 30A |
| Max output power | (0~72W...144W) x5CH Max.720W |
| DMX512 socket | XLR-3, RJ45, Green terminal |
| Control mode | DIM/CT/RGB/RGBW/RGBY |
| DIM Curve | 0.1～9.9 |
| Gray scale level | 8bit(256 levels)/16bit(65536 levels) |
| Photoelectric Isolation | Yes |
| Working temperature | -30℃～65℃ |
| Dimension | L169×W80×H39(mm) |
| Package Size | L182×W91×H41(mm) |
| Weight (G.W) | 500g |
| Input signal | DMX512/RDM |
| Input voltage | DC12V～DC24V |
| Max load current | 4A ×12CH Max. 48A |
| Max output power | (0~48W...96W) x12CH Max.1152W |
| DMX512 socket | XLR-5, RJ45, Green terminal |
| Control mode | DIM/CT/RGB |
| DIM Curve | 0.1～9.9 |
| Gray scale level | 8bit(256 levels)/16bit(65536 levels) |
| Photoelectric Isolation | Yes |
| Working temperature | -30℃～65℃ |
| Dimension | L180×W122×H39(mm) |
| Package Size | L193×W127×H41(mm) |
| Weight (G.W) | 700g |
| Input signal | DMX512/RDM |
| Input voltage | DC12V～DC24V |
| Max load current | 3A ×24CH Max. 72A |
| Max output power | (0~36W...72W) x24CH Max.1728W |
| DMX512 socket | XLR-3, XLR-5, RJ45, Green terminal |
| Control mode | DIM/CT/RGB |
| DIM Curve | 0.1～9.9 |
| Gray scale level | 8bit(256 levels)/16bit(65536 levels) |
| Photoelectric Isolation | Yes |
| Working temperature | -30℃～65℃ |
| Dimension | L300×W122×H39(mm) |
| Package Size | L309×W127×H41(mm) |
| Weight (G.W) | 1120g |
| Input signal | DMX512/RDM |
| Input voltage | DC12V～DC24V |
| Max load current | 3A ×32CH Max. 96A |
| Max output power | (0~36W...72W) x32CH Max.2304W |
| DMX512 socket | XLR-3, XLR-5, RJ45, Green terminal |
| Control mode | DIM/CT/RGB/RGBW |
| DIM Curve | 0.1～9.9 |
| Gray scale level | 8bit(256 levels)/16bit(65536 levels) |
| Photoelectric Isolation | Yes |
| Working temperature | -30℃～65℃ |
| Dimension | L300×W122×H39(mm) |
| Package Size | L309×W127×H41(mm) |
| Weight (G.W) | 1050g |
| Input signal | DMX512 |
| Input voltage | DC12V～DC24V |
| Output | 12A ×1CH + 0-10V ×1CH + 10V PWM ×1CH |
| Max output power | 144W/288W/(12V/24V) |
| Dimming range | 0~100% |
| Working temperature | -30℃～55℃ |
| Dimension | L175×W44×H30(mm) |
| Package Size | L178×W48×H33mm |
| Input signal | DMX512 |
| Input power | DC5V～DC24V |
| Max load current | 4A ×3CH Max 12A |
| Max output power | 60W/144W/288W(5V/12V/24V) |
| DMX512 socket | XLR-3 Green terminal (with signal amplification function) |
| Dimming range | 0~100% |
| Working temperature | -30℃～65℃ |
| Dimension | L125×W52×H40mm |
| Package Size | L135×W70×H50mm |
| Weight (G.W) | 300g |
| Input signal | DMX512 |
| Input voltage | DC5V～DC24V |
| Max load current | 5A ×4CH Max 20A |
| Max output power | 100W/240W/480W/(5V/12V/24V) |
| Dimming range | 0～100% |
| Working temperature | -30℃～55℃ |
| Dimension | L175×W44×H30(mm) |
