Product features:
| Input | 100-240Vac, 50-60Hz |
| Communication Mode | RF 2.4GHz |
| Output | 0-10V×2CH, 15mA×2CH |
| Anti Surge | ≤50A/0.1S |
| Working Temp. | -10°C~55°C |
| Dimensions | 86×86×50mm |
| Package Size | 105×105×63mm |
| Weight(G.W.) | 220g |
| Dimming interface | DMX/RDM,DALI,Push Dim |
| Output signal | 0-10V×4CH |
| Output signal logic | High potential |
| Input voltage | 100-240Vac/277Vac (277 Vac for North America only) |
| Dimming range | 0～100% |
| Dimensions | 175×44×30mm(L×W×H) |
| Pacakge size | 178×48×33mm(L×W×H) |
| Weight (G.W) | 110g±10g |
| Control Type | Dim / CT |
| Wireless Signal | RF 2.4GHz |
| Input Voltage | 100-240Vac |
| Output Signal | 0-10V×2 |
| Output Current | 15mA×2 Channel |
| Power Consumption | 1W |
| Dimensions | 86×86×36mm (LxWxH) |
| Package Size | 113×12×50mm (LxWxH) |
| Weight(G.W.) | 225g |
| Control Mode | RF wireless control and 0-10V, 10VPWM output control. |
| Input Voltage | 100-240Vac |
| Output Signal | 0-10V , 10V PWM |
| Wireless Signal | RF 2.4GHz |
| Working Temp. | -20℃~55℃ |
| Dimensions | L86×W86×H36(mm) |
| Package Size | L113×W112×H50(mm) |
| Weight(G.W.) | 225g |
| Input Voltage: | 5~24Vdc |
| Output: | 10VPWM |
| Wireless Signal: | RF 2.4GHz |
| Working Temp.: | -30℃~55℃ |
| Dimensions: | L55×W55×H21(mm) |
| Package Size: | L65×W65×H26(mm) |
| Weight(G.W.): | 70g |
| Input Voltage | 100～240Vac 50-60Hz |
| Output | 0-10V |
| Control Current | Max. 50mA |
| Switching Current | Max. 5A |
| Working Temp. | -10℃～35℃ |
| Dimensions | L86×W86×H50(mm) |
| Package Size | L106×W106×H60(mm) |
| Weight(G.W) | 220g |
| Output Signal | 1-10V, Max. 50mA |
| Switching Voltage | Max. 250Vac |
| Switching Current | Max. 5A |
| Anti Surge | ≤50A / 0.1S |
| Working Temp. | -10℃～55℃ |
| Dimensions | L86×W86×H50(mm) |
| Package Size | L106×W106×H60(mm) |
| Weight(G.W) | 220g |
